B-70010-02-0-8 | KSG Belc-H2.0 PZ72 XM round

Part No.B-70010-02-0-8
EAN 4015540759697
Weitere Produktinformationen Varianten
Area of application
Door technology
Area of application (specified)
Turn-Only
Application system
SECURY
Product type
Lever handle
Gross weight
780 G
Packing unit
2 EA
Minimum ordering unit
1 EA
Login

Please enter your login credentials to view prices or to order items

No content available

Attributes

Type of set
Lever set
Operation on inside/outside
Interior and exterior lever handle
Cover
Short backplate
user class
Grade 4
Clearance screw connection
90,5 mm
handle fixing
square spindle
Version
with lever handle H2.0
Diameter of lever handle
21 mm
Shape of lever handle
Mitre, straight
Lever handle height
70 mm
Type of fixing
concealed screw connection
Lever handle bearing
fixed bearing
Lever handle length
135 mm
Hole distance
72 mm
Form
oval
Material
Stainless steel
Lug
With lugs
Finish
matt
Type of backplate
Short backplate
Width of backplate
45 mm
Length of backplate
167 mm
Thickness of backplate
9 mm
Type of door
Entrance doors
Max. door leaf thickness
42 mm
Min. door leaf thickness
37 mm
Door material
Holz, Steel
Square follower
8 mm
Opening direction of hinges
Non-handed lever handle

Installation and assembly instructions

Installation instructions for project hardware B-70xxx / B-72xxx
PDF (4MB)
Deutsch
Variants
The following variants are available for this product:
article
article description
placeholder-shop
B-70010-00-0-1 | Lever handle | KSG Rondo H1.0 PC72 EV1 round
Lever handle, Hole distance 72 mm, Version with lever handle H1.0, overall length 167 mm, Opening direction of hinges Left/right
B-70010-00-0-8_ma00
B-70010-00-0-8 | Lever handle | KSG Rondo H1.0 PC72 matt ss round
Lever handle, Hole distance 72 mm, Version with lever handle H1.0, overall length 167 mm, Opening direction of hinges Non-handed lever handle
placeholder-shop
B-70010-01-0-8 | Lever handle | KSG Rondo H1.1 PC72 matt ss round
Lever handle, overall length 167 mm
B-70010-04-0-8_ma00
B-70010-04-0-8 | Lever handle | KSG BELC. P H3.0 PC72 matt ss round
Lever handle, overall length 167 mm
B-70010-07-0-8_ma00
B-70010-07-0-8 | Lever handle | KSG Legato H5.0 PC72 matt ss round
Lever handle, Hole distance 72 mm, Version with lever handle H5.0, overall length 167 mm, Opening direction of hinges Non-handed lever handle
B-70010-09-0-8_ma00
B-70010-09-0-8 | Lever handle | KSG Dirigent H7.0 PZ72 ss matt RD
Lever handle, Hole distance 72 mm, Version with lever handle H7.0, overall length 167 mm, Opening direction of hinges Non-handed lever handle
placeholder-shop
B-70010-10-0-1 | Lever handle | KSG Rondo H1.0 PZ72 EV1 square
Lever handle, Hole distance 72 mm, Version with lever handle H1.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-10-0-7 | Lever handle | KSG Rondo H1.0 PC72 9016 square
Lever handle, overall length 167 mm
placeholder-shop
B-70010-10-0-8 | Lever handle | KSG Rondo H1.0 PZ72 XM square
Lever handle, Hole distance 72 mm, Version with lever handle H1.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-12-0-8 | Lever handle | KSG Belc-H2.0 PZ72 XM square
Lever handle, Hole distance 72 mm, Version with lever handle H2.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-18-0-8 | Lever handle | KSG Tremolo H6.0 PC72 matt ss square
Lever handle, overall length 167 mm
placeholder-shop
B-70010-19-0-8 | Lever handle | KSG Dirig. H7.0 PC72 matt ss square
Lever handle, overall length 167 mm
placeholder-shop
B-70010-40-0-1 | Lever handle | KSG Rondo H1.0 UGL EV1 round
Lever handle, Version with lever handle H1.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-40-0-8 | Lever handle | KSG Rondo H1.0 UGL ss matt round
Lever handle, Version with lever handle H1.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-42-0-8 | Lever handle | KSG Belcanto H2.0 w/o PC hole matt ss rd
Lever handle, Version with lever handle H2.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-59-0-8 | Lever handle | KSG Dirig. H7.0 w/o PC hole ma ss sq
Lever handle, overall length 167 mm
placeholder-shop
B-70010-60-0-8 | Lever handle | KSG Rondo H1.0 BB72 matt ss round
Lever handle, Hole distance 72 mm, Version with lever handle H1.0, overall width 45 mm, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-62-0-8 | Lever handle | KSG Belc- H2.0 warded72 matt ss round
Lever handle, Hole distance 72 mm, Version with lever handle H2.0, overall length 167 mm, Opening direction of hinges Left/right
placeholder-shop
B-70010-67-0-8 | Lever handle | KSG Legato H5.0 warded72 matt ss round
Lever handle, overall length 167 mm
