B 2391 0202 | 65/24,round,DIN left,manual locking
Part No.B 2391 0202
EAN 4015540289392
1 Version found
B 2391 0201 | Panic shoot-bolt lock | 65/24,round,DIN right,manual locking
Part No.B 2391 0201
EAN4015540289385
No content available
Attributes
Backset
65 mm
Panic function
Yes
Faceplate length
235 mm
Interior square of follower
9 mm
Faceplate width
24 mm
Type of faceplate
Flachstulp
Finish of faceplate
matt
Cutout
with deadbolt cutout
Version
for manual locking
Follower
One-piece
Single-component material lock case
Steel
Single-component material follower
Steel
Single-component material faceplate
Stainless steel
Colour of faceplate
stainless steel
Number of leaves
double-leaf
Finish of lock case
galvanised
Deadbolt projection
3,5 mm
Lock case
closed
Width of lock case
95 mm
Length of lock case
165 mm
Thickness of lock case
16 mm
Characteristic of faceplate
projecting on both sides
Faceplate thickness
3 mm
Type of door
Anti-panic door
Door characteristic
Flush door
Door material
Steel
Opening direction of hinges
Left
Interior square of follower
9 mm
Version
for manual locking
Faceplate length
235 mm
Cutout
with deadbolt cutout
Single-component material lock case
Steel
Single-component material faceplate
Stainless steel
Follower
One-piece
Single-component material follower
Steel
Colour of faceplate
stainless steel
Number of leaves
double-leaf
Type No.
B 2391
Standard
DIN EN 179
Finish of lock case
galvanised
Finish of faceplate
matt
Panic function
Yes
Test certificates/Standards
DIN EN 179
Frame groove/Rebate
Flush door
Deadbolt projection
3,5 mm
Lock case
closed
Width of lock case
95 mm
Length of lock case
165 mm
Thickness of lock case
16 mm
Type of faceplate
Flachstulp
Faceplate width
24 mm
Characteristic of faceplate
projecting on both sides
Faceplate end
round
Faceplate thickness
3 mm
Type of door
Anti-panic door
Door characteristic
Flush door
Door material
Steel
Opening direction of hinges
Left
