B 1308 0001_ma00

B 1308 0012 | 30/24x160,sq,PC,deadbolt lock,nickel-sil

Part No.B 1308 0012
EAN 4015540582653
Product description Technical data Downloads
Area of application
Door technology
Area of application (specified)
Locks
Product type
Mortise lock
Gross weight
310 G
Packing unit
1 EA
Minimum ordering unit
1 EA
Login

Please enter your login credentials to view prices or to order items

19 Variants found
B 1308 0001_ma00
B 1308 0001 | Mortise lock | 25/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0001
EAN4015540580949
To the product
B 1308 0001_ma00
B 1308 0002 | Mortise lock | 30/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0002
EAN4015540580956
To the product
B 1308 0001_ma00
B 1308 0003 | Mortise lock | 35/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0003
EAN4015540580963
To the product
B 1308 0001_ma00
B 1308 0004 | Mortise lock | 40/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0004
EAN4015540580970
To the product
B 1308 0001_ma00
B 1308 0005 | Mortise lock | 45/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0005
EAN4015540580987
To the product
B 1308 0197_ma00
B 1308 0007 | Mortise lock | 55/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0007
EAN4015540770326
To the product
B 1308 0197_ma00
B 1308 0009 | Mortise lock | 65/24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0009
EAN4015540770333
To the product
B 1308 0001_ma00
B 1308 0011 | Mortise lock | 25/24x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0011
EAN4015540584091
To the product
B 1308 0001_ma00
B 1308 0013 | Mortise lock | 35/24x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0013
EAN4015540584107
To the product
B 1308 0001_ma00
B 1308 0014 | Mortise lock | 40/24x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0014
EAN4015540584114
To the product
B 1308 0001_ma00
B 1308 0015 | Mortise lock | 45/24x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0015
EAN4015540584084
To the product
B 1308 0017_na00
B 1308 0017 | Mortise lock | 55/24x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0017
EAN4015540770340
To the product
B 1308 0197_ma00
B 1308 0019 | Mortise lock | 65/24x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0019
EAN4015540770357
To the product
B 1308 0001_ma00
B 1308 0021 | Mortise lock | 24/U24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0021
EAN4015540579547
To the product
B 1308 0001_ma00
B 1308 0022 | Mortise lock | 29/U24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0022
EAN4015540579554
To the product
B 1308 0001_ma00
B 1308 0023 | Mortise lock | 34/U24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0023
EAN4015540579561
To the product
B 1308 0001_ma00
B 1308 0024 | Mortise lock | 39/U24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0024
EAN4015540579578
To the product
B 1308 0001_ma00
B 1308 0025 | Mortise lock | 44/U24x160,square,PC,deadbolt lock,ss
Part No.B 1308 0025
EAN4015540579585
To the product
B 1308 0001_ma00
B 1308 0071 | Mortise lock | 25/16x160,sq,PC,deadbolt lock,nickel-sil
Part No.B 1308 0071
EAN4015540619946
To the product
View all variants
No content available

Attributes

Backset
30 mm
Hole distance
92 mm
Faceplate length
160 mm
Faceplate width
24 mm
Type of faceplate
Flachstulp
Finish of faceplate
painted
Single-component material lock case
Steel
Single-component material deadbolt
Zinc die-cast
Single-component material faceplate
Steel
Colour of faceplate
nickel silver colour
Number of leaves
einflügelig
Type No.
B 1308
Finish of lock case
galvanised
Deadbolt throw
20 mm
Characteristics of deadbolt
Standard
Lock case
Open
Width of lock case
42 mm
Length of lock case
100 mm
Thickness of lock case
16 mm
Deadbolt
2-turn
Characteristic of faceplate
projecting on both sides
Faceplate thickness
3 mm
Type of door
Narrow stile door
Door characteristic
Flush door
Door material
Steel, Aluminium
Opening direction of hinges
Left/right
